Model Number : D112007
Place of Origin : Guangdong, China
Brand Name : LI Solar
Packaging Details :
* Use high hardness custom sponge to strengthen the battery* 5 layers of dangerous goods export corrugated carton
* Wrap the outer box with waterproof tape
* Free bus bars and bolts pack together in a sealed envelope.
Supply Ability : 1000 Pack/Packs per Day
MOQ : 1 units
Price : Negotiation
Size : 150*65*94mm
Voltage : 12.8v ~ OEM
Capacity : 7Ah
Power Source : AC Adaptor, Car, Gas Generator, Solar Panel, Other
Battery Type : LiFePO4
Special Features : Wireless Charging, Remote Control, Type C, Flashlight, jump starter
System Voltage : 10-14.6V
Keywords : Ah Li-ion battery for Golf Carts



| MODEL | | |
| Rated capacity (Ah) | 10 | |
| Rated energy (Wh) | 85 | |
| Normal voltage (V) | 12.8 | |
| Discharge termination voltage (V) | 10 | |
| Charging voltage (V) | 14.6 | |
| Internal resistance (mΩ) | ≤160 | |
| Standard Charge (V) | Continuous current: 0.2C5A Continuous voltage: 14.6V Cut-off current: 0.01 C | |
| Standard discharge (V) | Continuous current: 0.2C5A Cut-off voltage: 10.0V | |
| Maximum charge continuous current | 1.0 C | |
| Maximum discharge continuous current | 1.5 C | |
| Operating temperature range (℃) | Charging 0~+45℃ | |
| Weight (kg) | 0.8 | |
| Size (mm) | 151*65*95 | |
| BMS Protection Board Specifications | | |
| Overcharge detection voltage (V) | 3.90V±50mV | |
| Overcharge Recovery Voltage (V) | 3.80V±100mV | |
| Overdischarge detection voltage (V) | 2.00V±100mV | |
| Overdischarge recovery voltage (V) | 2.30V±100mV | |
| Operating current (A) | 6 | |
| Overcurrent detection value (A) | 45± | |
| Board Internal Resistance (mΩ) | ≤50 | |





|
|
12V 7Ah Lithium Ion Battery for Electric Folklifts Home Solar Energy Storage Solution Images |
